ST086A Automatic Paper Board Slitting Machine is one of ST paper board slitting machine series it’s professional board slitting machines for slitting the grey board with high accuracy and great efficiency. Compared with paper cutting machines, board slitting machines can slit the grery boards without any rough and bevel edges, which are the professional machines for supporting the hardcover book making, table calendar, gift box making..etc. In ST we have the semi-automatic and fully-automatic board slitters for meeting the different customers’ different requirements. ST086A Automatic Paper Board Slitting Machine have the automatic board stacking and waste collection device, which can improve the production efficiency and save the labor intensity greatly. Thus it is the best choice for matching the case making machine productions especially for the bookbinding industry and board manufacturing factory.
|
· Machine Parameter |
|
| · Overall size | · 6100x5000x2300(mm) |
| · Weight | · 2500(kg) |
| · Votage | · 380/220(v) |
| · Power | · 4.1(kw) |
| · Speed | · 70(m/min) |
| · Machine Color | · White ans grey |
|
· Technology Parameter |
|
| · Max cutting size | · 1200×1100(mm) |
| · Min cutting size | · 140×90(mm) |
| · Board thickness | · 0.8-4(mm) |
| · Waste width | · 5(mm) |
1. The Max. and Min. sizes of the cases are subjected to the sizes and quality of the paper.
2. The speed of the machine depends on the sizes of the cases.
3. We don’t provide air compressor.
